Nylon Sheets

Get a Price/Quote

Product Details:

Type Nylon Sheets
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Price And Quantity

Minimum Order Quantity 100 Kilograms

Product Specifications

Type Nylon Sheets

Trade Information

Payment Terms Cash Advance (CA)
Supply Ability 5000 Kilograms Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

Nylon Sheets are used for manufacturing various assemblies including bushings, bearings, gear, wear components, insulators, and sprockets. Nylon Sheet is also admired for having easy machinability and having low friction coefficient. Nylon Sheets are one of the most common plastics used to create everything from parachutes to food delivery boxes.

Product Details :

Brand Name	Sustamid 6G
Generic Name	PA6G / Cast Nylon / Polyamide
Tensile Modulus of elasticity	3400 MPa as per DIN EN ISO 527
Water Absorption	2.5% as per DIN EN ISO 62 Test Method
Density (g/cm Cube)	1,15
Size	Sheets : 6 mm to 150 mm in 2500 x 1250 mm and 2000 x 1000 mm Rods : 50 mm to 610 mm Dia
Brand	Sustamid 6G / Sustamid 6
Usage/Application	Mechanical engineering\|Aircraft construction\|Food processing industry\|Offshore\| Vehicle construction

Semi-Crystalline thermoplastics

Generic Name : PA6 (EXTRUDED NYLON), PA6G(Cast Nylon)

Brand Name: Sustamid 6/ Sustamid 6G

Special properties :

Good toughness
Very good noise and vibration absorption
Very good sliding properties
high absorption of moisture of up to 3 % in standard atmosphere
High abrasion resistance
High mechanical strength coupled with high impact strength
Excellent machinability
Good adhesive properties
Good weldability

Chemical Resistance	Resistant to	Hydrocarbon, Alkalies, Grease , Oil , Fuels , Ketones , Ether
	Non resistant to	halogens, mineral acids & certain organic acids, oxidising agents

Typical areas of application

Mechanical engineering
Aircraft construction
Food processing industry
Offshore
Vehicle construction

Standard Sizes :

Sheets : 6 mm to 150 mm in
2500 x 1250 mm
2000 x 1000 mm
Rods : 50 mm to 610 mm Dia

in 1000 mm / 3000 m Length

Colours : Ivory White , Black , Yellow , Blue , Green

Variants/Grades :

SUSTAMID 6 FG	for direct conact of food.
SUSTAMID 6MO	Self lubricated with carbon content
SUSTAMID 6 GC	Unmodified Extruded nylon
SUSTAMID 6 GC MO
SUSTAMID 6 GF 30	Glass reinforcement 30% for heavy loaded parts
SUSTAMID 6 ESD 60	Antistatic agents
SUSTAMID 6 FR	Flame retardent with UL94 V0 certification.
SUSTAMID 6 GF	Glass filled extruded nylon
SUSTAMID 6G	Mechanically strong & good impact values
SUSTAMID 6G MO	Self lubricated & carbon filled
SUSTAMID 6G HS	Heat stablised - high working temprature then Sustamid 6G
SUSTAMID 6G ESD 60	electrically conductive
SUSTAMID 6G ESD 90	electrically conductive
SUSTAMID 6G OL	Self lubricated
SUSTAMID 6G PLUS	Reinforcment( Heavly loaded parts )
SUSTAMID 6G M	Internally lubricated
SUSTAMID 6G M OL	Low friction as compared to Sustamide 6G
SUSTAMID 6G LU	Low friction and good abrasion resistance
SUSTAMID 6G GK	low deformation under pressure
SUSTAMID 6G PD 120	High impact strength
SUSTAMID 6G PD 140	High impact strength
SUSTAMID 6G GLIDE	Improved sliding properties , approx five time better pv values then Sustamide 6G
SUSTAMID 6G GLIDE PLUS	Improved sliding properties , approx five time better pv values then Sustamide 6G
